36V 560Ah Battery (IE36560)
36V 560Ah Battery (IE36560)
Couldn't load pickup availability
Our 36V batteries are an ideal choice for CLASS 1 & 2 forklifts, including narrow aisle and high-rack stackers. Their consistent discharge enables your fleet to maneuver efficiently in tight warehouse spaces.
The IE36560 is one of our 36V batteries with a large capacity, providing steady and ample power for your material handling needs.
Taranis battery modules are built with lithium iron phosphate cells, requiring no maintenance. Additionally, our batteries support rapid charging anytime, anywhere, thanks to their opportunity charging capability. With a 5-year warranty and a lifespan of up to 10 years, our batteries deliver lasting performance.
Using Taranis LiFePO4 batteries can significantly boost your warehouse productivity.
| Detailed Specs | ||
| 560 Ah - 21.5kW | ||
| Chemistry | LifePo4 | |
| Configuration | 12 Series, 2 Parallel |
|
| Voltage | 36V | |
| Capacity | 560 Ah - 21.5kW | |
| Performance | ||
| Continuous Discharge | 450A |
|
| Peak Discharge | 650A (30s) |
|
| Voltage Range | 30.0 - 43.8V |
|
| Charge Voltage | 43.8V |
|
| Max Charge Current | 200A |
|
| Physical | ||
|
Length |
940mm (37.0") | |
| Width | 420mm (16.6") | |
| Height | 340mm (13.4") | |
| Weight | 160 Kg (350lbs) | |
| Safety Features | ||
|
Battery Management System |
Over Voltage, Under Voltage, Over Current, Temperature protection Battery equipped with Bluetooth monitoring Option for Internal Heating for sub zero operations Option for paralleling multiple batteries |
|
